Efficient and economic operation due to high throughput rate and short mixing cycles.
The large double "S" shaped mixing ploughs and high capacity blender rotate continuously during loading with pre-batched material and blender rotate in opposite direction, this combination guarantees fast, highly intensive preparation as well as perfect homogenization of the mixing sand.
Feature Intensive sand mixer
Easy access to all wear parts for quick replacement.
Low maintenance requirement due to robust components and minimum wear of mixing tools and mixer bowl.
An optional Sand Controller ensures ideal sand quality by enabling integration of dosing, mixing and moistening.An optional precision weighing control system for used sand and additives.
Specially designed for green sand plant.
Fully Automated Operation.
GS series high efficiency rotor type sand mixer/sand mixing machine
|
Model |
GS20-55 |
GS20-75 |
GS22-75 |
GS22-90 |
GS25-110 |
GS25-132 |
GS29-200 |
|
Name |
sand mixer |
sand mixer |
sand mixer |
sand mixer |
sand mixer |
sand mixer |
sand mixer |
|
(mm) Disk diameter |
2000 |
2000 |
2240 |
2240 |
2500 |
2500 |
2850 |
|
(t/h) Capacity |
20~28 |
25~32 |
30~35 |
35~40 |
40~50 |
50~60 |
60~80 |
|
(KW)Main motor power |
55 |
75 |
75 |
90 |
110 |
132 |
200 |
|
(KW)Rotor motor power |
2×30 |
2×37 |
2×45 |
2×45 |
2×45 |
2×55 |
2×55 |
|
(r/min) Main shaft speed |
31.72 |
31.72 |
27.32 |
27.32 |
27.3 |
27.32 |
25.4 |
|
(r/min)Rotor speed |
1270 |
1270 |
975 |
975 |
950 |
950 |
850 |
Inquiry with sand mixing capacity,we will provide you with the best solutions!
